Par Meter and Spectrometer

Introducing our cutting-edge Par Meter and Spectrometer, a technological marvel crafted for precision and performance. Engineered with a high-speed CPU processor and a high-precision electronic CCD optical sensor, this device operates on the principle of long focal cross asymmetric CT spectroscopy system, delivering unparalleled accuracy and stability.

Enjoy the savings vs others at $500+ for just Par readings!

If you like to download data to a computer:  Software Program Here to download data   This software is in Beta testing and functions are limited but will be added in the future.  It does not work on all computers and unfortunately, we do not have current support for this - it was built by a 3rd party.

Key Features:

1. Advanced Optical Technology:

• Optical resolution of 2nm for precise measurements.
• Wider wavelength range ensures comprehensive analysis.
• Stable performance under various conditions.

2. Electronic Shutter Technology:

• Minimum integration time as low as 50us, allowing measurement of strong and weak optical signals.
• Adjustable integration time for versatility in signal detection.

3. Sleek and Portable Design:

• All-aluminum alloy precision carving for a lightweight and portable body.
• Modern design, completely discarding the bulk of traditional models.

4. Open Operating System:

• Upgraded system with a more open operating system and source code.
• Facilitates intelligent product applications and provides space for unlimited instrument upgrades.

5. Intuitive User Interface:

• 3.5-inch high-definition IPS capacitive touch screen for a vibrant display.
• High resolution for more content on a single screen, realistic graphics, and a smoother user experience.
• Thoughtful interface design enhances usability.

6. Quick and Convenient:

• Quick on/off functionality for swift operations.
• One-click testing for seamless measurements.
• Large battery capacity allows for 24 hours of extended testing time.

Whether you're a professional researcher, scientist, or enthusiast, our Par Meter and Spectrometer redefine the standards of accuracy, convenience, and portability. Elevate your experiments and measurements with a device designed for the future of scientific exploration.

B. Function Description:

• PPFD PAR:

  • Measures Photosynthetic Photon Flux Density for optimal plant growth.

• Spectral Distribution Map:

  • Provides a detailed map of the spectral distribution for comprehensive analysis.

• Related Color Temperature Tc (K):

  • Offers color temperature information for accurate lighting assessment.

• Illuminance E (lx):

  • Measures the level of illuminance in lux for well-lit environments.

• Irradiance Ee (W/m²):

  • Determines irradiance for a complete understanding of light intensity.

• Chromaticity Coordinates (x, y):

  • Presents chromaticity coordinates for precise color representation.

• Relative Spectral Power Distribution P(λ):

  • Illustrates the relative distribution of spectral power.

• Color Rendering Index Ra, Ri (i=1-15):

  • Evaluates color rendering accuracy across a spectrum of indices.

• Color Rendering Index:

  • Measures the device's ability to reproduce colors accurately.

• Chromaticity Coordinate Map:

  • Displays a map of chromaticity coordinates for comprehensive analysis.

• Color Tolerance Map SDCM:

  • Illustrates color tolerance using Standard Deviation of Color Matching.

• Main Wavelength, Peak Wavelength, Half Width:

  • Provides crucial information about the light spectrum.

• Light to Dark Visual Ratio S/P:

  • Evaluates the visual experience by assessing light-to-dark ratios.

• Color Purity, Red Ratio, Green Ratio, Blue Ratio:

  • Analyzes color components to ensure accurate representation.

• Can Export Spectral Data per Nanometer:

  • Allows for detailed spectral data export for in-depth analysis.

• More Functional Parameters Can Be Customized:

  • Tailor the device to specific requirements with customizable parameters.

C. Main Technical Indicators:

• Model and Name:

  • M400 Spectral Color Illuminometer.

• Wavelength Range:

  • 380nm~780nm for comprehensive spectral coverage.

• Split Mode:

  • Long focal cross asymmetric CT split beam system.

• Sensor:

  • High-precision CCD for accurate light sensing.

• Spectral Bandwidth (FWHM):

  • 2nm for detailed spectral analysis.

• Spectral Resolution:

  • 0.2nm for high-resolution data.

• x, Y Coordinate Value x, y Accuracy:

  • ±0.0015 accuracy; ±0.0005 repeatability.

• Wavelength Accuracy:

  • ±0.5nm for precise wavelength measurements.

• Wavelength Data Output Interval:

  • 1nm; EXCEL can export data corresponding to each nanometer.

• Illumination Accuracy Level:

  • Level 1 (±4% reading ±1 reading) for reliable results.

• Color Rendering Accuracy:

  • ±1.5% for accurate color representation.

• Photosensitive Surface:

  • Ф 10mm for efficient light capture.

• Screen Type:

  • 3.5-inch high-definition IPS capacitive touch screen for intuitive operation.

• Chromaticity Standard Accuracy:

  • ±0.0025, traceable to NIM for reliable color temperature assessments.

• Color Temperature Range:

  • 1000K~100000K for versatile lighting conditions.

• Stray Light:

  • ≤0.3% to minimize interference.

• Illuminance Measurement Range:

  • 0.1Lux~2000Klux for diverse lighting environments.

• Measurement Mode:

  • Single test/continuous test for flexibility in testing scenarios.
